Exemple d'application
Siemens Relais à semi-conducteurs 3RF20501AA02 50 A Tension de contact (max.): 230 V/AC 1 pc(s)
EAN :
Ref. fabricant :
Code produit :
Type de produit
Relais à semi-conducteurs
Tension de commande (min.)
24 V/DC
Tension de commande (max.)
24 V/DC
Tension de contact (max.)
230 V/AC
Courant de charge (max.)
50 A
Fiche technique (PDF)
Quantité (pièce(s))
Economie
prix de l'emballage (HT)
1
-
41,66 €
3
3% = 1,35 €
40,31 €
5
5% = 1,89 €
39,77 €
10
5% = 2,25 €
39,41 €
25
6% = 2,66 €
39,00 €
Les remises sur volume varient selon les vendeurs
Économiser 0,00 €
Nombre
Total (41,66 € / unité(s))
41,66 €
HT
dont 0,02 € d’éco-part
Livraison gratuite avec
Droit de retour de 14 jours inclus (30 jours avec)
Points forts et détails
Relais semi-conducteur Sirius 3RF20, 45 mm de largeur
Nos services :
Caractéristiques techniques
- Fréquence : 50/60 Hz
- Tension d'isolement : 600 V
- 1000 V/μs
- 800 V
- Type de produit
Relais à semi-conducteurs
- Type
3RF2050-1AA02
- Tension de commande (min.)
24 V/DC
- Tension de commande (max.)
24 V/DC
- Gamme de tension de commande
24 - 24 V/DC
- Tension de contact (min.)
24 V/AC
- Tension de contact (max.)
230 V/AC
- Courant de charge (max.)
50 A
IP20
- Conforme à la norme RoHS
oui
- Contenu
1 pc(s)
- Alim.
24 - 230 V/AC
1
VRAI
15-24 V
50 A
DC
50 A
Documents et téléchargements
Fiche technique
Fiche technique 186012 Siemens Relais à semi-conducteurs 3RF20501AA02 50 A Tension de contact (max.): 230 V/AC 1 pc(s)
Conseils d'utilisation et de sécurité
Conseils d'utilisation et de sécurité 186012 Siemens Relais à semi-conducteurs 3RF20501AA02 50 A Tension de contact (max.): 230 V/AC 1 pc(s)
Description
Semiconductor relay, 1-phase 3RF2 Overall width 45 mm, 50 A 24-230 V / 24 V DC screw terminal solid-state relay SIRIUS 3RF20 for switching resistive/inductive loads, e.g. of heaters or valves in a bottling plant.
The devices are non-wearing and silent and are therefore ideal for noise-sensitive areas (offices, hospitals). They are also extremely reliable at high switching frequencies. The compact design saves space on the cooling surface. The solid-state relays can also be expanded for a wide range of applications by simply clicking on the standardized 3RF29 function modules. The devices are approved for worldwide use (e.g. IEC and UL/CSA).
The solid-state relays are available as single-phase devices in two widths, or as three-phase devices. They are available for different power ratings and rated operating voltages. Designed for AC or DC operation, they are available with screw, spring-type or ring terminal lug connections.
In addition to the 3RF29 function modules, control connectors and terminal covers are also available as accessories.
Simple, efficient and always up to date - SIRIUS modular system.
The devices are non-wearing and silent and are therefore ideal for noise-sensitive areas (offices, hospitals). They are also extremely reliable at high switching frequencies. The compact design saves space on the cooling surface. The solid-state relays can also be expanded for a wide range of applications by simply clicking on the standardized 3RF29 function modules. The devices are approved for worldwide use (e.g. IEC and UL/CSA).
The solid-state relays are available as single-phase devices in two widths, or as three-phase devices. They are available for different power ratings and rated operating voltages. Designed for AC or DC operation, they are available with screw, spring-type or ring terminal lug connections.
In addition to the 3RF29 function modules, control connectors and terminal covers are also available as accessories.
Simple, efficient and always up to date - SIRIUS modular system.
